according to IEC 60947-5-6 (NAMUR, DIN 19234) 4 inputs
Slave type Standard slave
PWR / CHK LED dual-LED green / red
green: AS-Interface voltage, normal operation
red: communication error or address 0
Rated operating voltage 26.5 ... 31.6 V from AS-Interface
Rated operating current ≤ 70 mA
Switching point OFF ≤ 1.5 mA
ON ≥ 4.5 mA
Voltage 10.9 V
Current 14.6 mA
Power 40 mW
Type of protection EEx ia IIC
Degree of protection IP54 according to EN 60529
Connection screw terminals
Mass 1.5 kg
Mounting screw mounting
