Reference target receiver
Light type 660 nm visible red light
Upper limit of the sensing range 30000 mm
Rated operating voltage 6 ... 16 V DC , ripple 5 %SS
Time delay before availability 20 ms
utput type 1 NAMUR output N2, NO/NC, cabling programmable
Switch-on delay 5 ms
Switching frequency ≤ 100 Hz
Degree of protection IP64 according to EN 60529
Connection terminal compartment PG9, ≤ 2.5 mm2
